With virtual permission...of my friend Nico Sgarlato who in the past was in charge with Delta Editrice in Italia, I add this multi-view line drawing scanned from " Caccia e Bombardieri 1945-1955 " by Corrado Barbieri published during 1975. Nico wrote a companion book for the years 1956-1975 for the same Delta Editrice publisher. I found this drawing quite interesting because P2V-7 may be compared with earlier versions of the Neptune. Note that it's shown with a dorsal twin turret but if provision truly existed to receive it, I never saw it installed on a P2V-7, but I am sure that someone in the News Groups has the picture to contradict. Optimized for 800x600 screen. I send via NG a 1000x740 if requested.
